Retail Lighting
High Lumen Flex LED Strip 160lm/w
Item No. HM-SX144F010W24-2835 Light Source SMD2835 LED Qty/M 144LEDs/m Input Voltage DC24v PCB 10mm/2oz Length 5,000mm Size Width 10mm,Height 1.2mm Cutting Length 125mm Lifespan 50,000H Working Temperature -20℃-40℃ Storage Temperature -20℃-45℃ Warranty 3 years
- System
- Retail Lighting
- Product Family
- LED Strip Lights
- Product Type
- SMD / Standard LED Strips
Product Gallery
Product Views
Product Video
See the product in action
Product Details
Technical Information
| Item No. | HM-SX144F010W24-2835 |
| Light Source | SMD2835 |
| LED Qty/M | 144LEDs/m |
| Input Voltage | DC24v |
| PCB | 10mm/2oz |
| Length | 5,000mm |
| Size | Width 10mm,Height 1.2mm |
| Cutting Length | 125mm |
| Lifespan | 50,000H |
| Working Temperature | -20℃-40℃ |
| Storage Temperature | -20℃-45℃ |
| Warranty | 3 years |
| Power | 10W/m | |||||
| Ra | 80+ | 90+ | ||||
| CCT | 2700k | 3000k | 4000-6000k | 2700k | 3000k | 4000k-6000k |
| Brightness | 1350 | 1400 | 1600 | 1250 | 1300 | 1350 |
| Efficiency(Lm/W) | 135 | 140 | 160 | 125 | 130 | 135 |
| Installation Length | 6m |
| Power | 15W/m | |||||
| Ra | 80+ | 90+ | ||||
| CCT | 2700k | 3000k | 4000-6000k | 2700k | 3000k | 4000k-6000k |
| Brightness | 2025 | 2100 | 2400 | 1875 | 1950 | 2025 |
| Efficiency(Lm/W) | 135 | 140 | 160 | 125 | 130 | 135 |
| Installation Length | 5m |
